Given the in-flight structural failure of the tail section of U.S.S. The leading edge of the fins, which were subject to very heavy aerodynamic loads, were not firmly attached to any main, load-bearing structural element, but merely to weaker, intermediate framing.
In order to make the lower fin visible from the control car, however, the design was changed to shorten the fins, and the modified fins were attached to only two main rings (numbers 0 and 17.5).
In the original design, the fins were to have been attached to the hull at three main rings: Ring 0 at the tail Ring 17.5 at the center of the fin and Ring 35 at the leading edge of the fin, which carried heavy loads. Macon.įinal, modified stabilizer arrangement of Akron/Macon, showing main rings (highlighted in yellow) Both Rosendahl and zeppelin commander Hugo Eckener believed it was important for the officers to have an unobstructed view of the lower fin, and this requirement led to a modification of Arnstein’s original design which would later have tragic consequences in the crash of U.S.S. Experience had taught airship commanders that the lower fin was vulnerable to damage in operations near the ground Charles Rosendahl had been aboard the Graf Zeppelin during its difficult overweight takeoff from Los Angeles during its 1929 Round-the-World flight, when the lower fin, which had not been visible from the control gondola, only narrowly missed hitting power lines at the edge of the field. One other design element which would have great significance in light of later events was the shape and position of the stabilizing fins, which were modified from their original design to accommodate a Navy request that the lower fin be visible from the control car. Traditional German zeppelin design included a cruciform tail structure for strength, which Arnstein and his design team eliminated in the Akron and Macon. One of the eight engine rooms aboard U.S.S. Placing the engines in a straight line along each of the lower keels, however, allowed for a much simpler and lighter design, and was accepted as a better alternative than the additional weight and complexity of the framework that would have been required to stagger them. In earlier zeppelins, the staggering of engines at differing heights along the hull allowed each propeller to operate in clean air, undisturbed by the prop wash from the engine in front of it, whereas the propellers on Akron and Macon operated in the disturbed air created by the engines ahead of them. The mounting of the engines on the two lower keels did create one design element which was accepted only as a compromise the four engines on either side were mounted in a straight line, and not staggered as the external power cars of earlier zeppelins had been. The 560 hp Maybach VL-2 engines were connected to outrigger propellers by long shafts with bevel gears which allowed the propellers to be rotated to provide thrust not only forward and reverse, but also vertically downward to assist in takeoffs and landings. As naval airship doctrine eventually developed, rather than the airplane extending the scouting range of the airship, it was the airship which extended the scouting range of the airplane. The giant airships made large, slow targets which were highly vulnerable to destruction by an enemy’s planes.Īlthough the Navy originally envisioned the airships as scouting vessels which carried airplanes for fighter defense, over time (and over the objection of officers like Charles Rosendahl) the Navy eventually realized that the vulnerable airship itself was best employed in the background, out of sight of the enemy the airship’s function would be to carry scouting planes within range of the enemy. Airplanes greatly increased the range and area over which the airship could search for the enemy, but also addressed the airship’s own inherent weakness its vulnerability to attack. The capacity to embark and deploy fixed-wing aircraft was the essential element of Akron and Macon’s ability to serve as naval scouts. Aircraft were launched and retrieved by means of a trapeze, and could enter and exit the hangar though a large T-shaped opening at the bottom of the hull. The ships were equipped with hangars, approximately 75′ long x 60′ wide x 16′ high, which could stow and service up to five aircraft in flight. N2Y-1 training plane beneath trapeze and T-shaped opening of Akron’s hangar deck
